CATO Chief Fire Extinguisher Cabinets

CATO Chief Fire Extinguisher Cabinet Exploded Diagram
 Components and Materials


The CATO Chief Series features injection molded plastic construction with UV inhibitors, a scored acrylic break panel, and a hexagonal locking mechanism.  The numbered components correspond to the exploded diagram above.

1. Hex Key and Lock
The all-plastic hexagonal locking mechanism eliminates metal lock components that could rust or corrode. The matching plastic hex key allows the front trim and acrylic panel to be removed for fire extinguisher inspection and maintenance.

2. Outer Trim Frame
Manufactured from injection-molded, high-impact polystyrene with a nominal wall thickness of 0.110 inches. UV inhibitors are incorporated into the material to improve resistance to ultraviolet exposure. Available in red or white.

3. Scored Acrylic Panel
 Manufactured from 0.080-inch acrylic, with a scored grid pattern designed to facilitate emergency access using the break tool. Available in clear or red; CATO identifies red acrylic as providing the best outdoor UV resistance.

4. Main Body Tub
Manufactured from injection molded, high impact polystyrene with a nominal wall thickness of 0.110 inches.  Contains UV inhibitors for improved resistance to sunlight exposure.  The plastic construction will not rust or corrode like metal cabinet bodies.

5. Hammer (Break Tool)
Manufactured from injection molded polypropylene with a ribbed grip and aluminum striking tip.  The hammer is attached using a clear nylon coated stainless steel cable. Hammer color matches the cabinet trim.  A stainless steel break bar is also available as an alternative break tool option.



Cato Chief
CATO 10501-H Chief Plastic 5 lbs. Fire Extinguisher Cabinet - White

White plastic fire extinguisher cabinets made in the USA. Three models to fit 2½ and 5 lbs. ABC dry chemical fire extinguishers. The CATO 10501-H Chief plastic 5 lbs. fire extinguisher cabinet in white is design to hold a 5 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust.  The...

[more info...]
Price: $29.80
Cato Chief
CATO 10551-H Chief Plastic 5 lbs. Fire Extinguisher Cabinet - Red

Red plastic fire extinguisher cabinets made in the USA. Holds 2½, and 5 lbs. ABC dry chemical fire extinguishers. The CATO 10551-H Chief plastic 5 lbs. fire extinguisher cabinet in red is design to hold a 5 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust.  The CATO...

[more info...]
Price: $29.80
Cato Chief
CATO 11001-H Chief Plastic 10 lbs. Fire Extinguisher Cabinet - White

White plastic fire extinguisher cabinets made in the USA. Three models to fit 2½, 5, 6, and 10 lbs. ABC dry chemical fire extinguishers. The CATO 11001-H Chief plastic 10 lbs. fire extinguisher cabinet in white is design to hold a 10 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust. The CATO...

[more info...]
Price: $35.73
Cato Chief
CATO 11051-H Chief Plastic 10 lbs. Fire Extinguisher Cabinet - Red

Red plastic fire extinguisher cabinets made in the USA. Holds 2½, 5, 6, and 10 lbs. ABC dry chemical fire extinguishers. The CATO 11051-H Chief plastic 10 lbs. fire extinguisher cabinet in red is designed to hold a 10 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust. The CATO...

[more info...]
Price: $35.73
Cato Chief
CATO 12001-H Chief Plastic 20 lbs. Fire Extinguisher Cabinet - White

White plastic fire extinguisher cabinets made in the USA. Three models to fit 2½, 5, 6, 10, and 20 lbs. ABC dry chemical fire extinguishers. The CATO 12001-H  Chief plastic 10 lbs. fire extinguisher cabinet in white is designed to hold a 10 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust....

[more info...]
Price: $61.09
Cato Chief
CATO 12051-H Chief Plastic 20 lbs. Fire Extinguisher Cabinet - Red

Red plastic fire extinguisher cabinets made in the USA. Holds 2½, 5, 6, 10, and 20 lbs. ABC dry chemical fire extinguishers. The CATO 12051-H  Chief plastic 10 lbs. fire extinguisher cabinet in red is designed to hold a 10 lbs. fire extinguisher.  Because there are no metal parts, this cabinet can not rust. The...

[more info...]
Price: $62.49
